Prices for DataMite Data Logger Sensors and Systems

[Company Logo Image] Performance Trends Inc

Producing Quality Computer Tools for Racers and Engine Builders since 1986

for pictures and an overview of our DataMite USB data loggers

for various Package Prices

DataMite Mini USB Prices (available now, Nov 2008):

Part #	Picture	Description	Sug Retail
DMM-IDP		DataMite Mini Inertia Dyno Package (everything needed to measure dyno RPM and calculate corrected torque and HP vs RPM curves). It includes: DataMite Mini USB with 2 RPM channels and 2 analog channels. Dyno RPM sensor and harness and magnets USB communications cable Basic Dyno DataMite Software	$ 499
DMM-BCT		15 ft Dual thermocouple breakout cable	25
DMM-BCA2		2 ft dual analog breakout cable	35
DMM-IWS		Internal Weather Station Sensor and Fan	175

DataMite III USB Prices (Nov, 2008):

Part #	Picture	Description	Sug Retail
DT3-DS		DataMite III USB Inertia Dyno System (everything needed to measure dyno RPM and calculate corrected torque and HP vs RPM curves). It includes: DataMite III USB with 3 RPM channels and 12 analog channels. Dyno RPM sensor, harness and magnets Engine RPM tach input USB communications cable 50 Hz sampling rate Basic Dyno DataMite Software	$ 699
DT3-DRS		DataMite III USB Inertia Drag Race System. It includes: DataMite III USB with 3 RPM channels and 12 analog channels. 3 axis accelerometer Engine RPM tach input Driveshaft RPM sensor and harness and magnet collar USB communications cable 1 Gig SD memory card Lighted Start/Stop logging switch 50 or 100 Hz sampling rate Basic Drag Race DataMite Software	$ 699
DT3-DRS		DataMite III USB Inertia Road Race/Circle Track System. It includes: DataMite III USB with 3 RPM channels and 12 analog channels. 3 axis accelerometer Engine RPM tach input USB communications cable 1 Gig SD memory card Lighted Start/Stop logging switch GPS enabled for optional DT3-GPS 50 or 100 Hz sampling rate Basic Road Race/Circle Track DataMite Software	$ 699
DT3-TC4		4 Internal K Thermocouple channels	200
DT3-BCA2		2 ft 2 channel analog breakout cable	35
DT3-BCA5		2 ft 5 channel analog breakout cable	55
DT3-GPS		External fast responding GPS (global positioning) sensor for lap timing and track mapping	349
DT3-LSA		Land & Sea Torque Arm Connector Kit	145
DT3-IWS		Internal Weather Station Sensor and Fan	175

Black Box II Prices (Nov, 2008):

Note: Black Box II can use most all sensors for the DataMite and DataMite II. The parts in the table below are unique to Black Box II.

Part #	Picture	Description	Sug Retail
BB2-IDP		Std Black Box II Inertia Dyno Package, including: Black Box II with 2 RPM channels and 5 analog channels. Dyno RPM sensor and harness Engine RPM harness and connector for tach signal or optional inductive pickup. Serial downloading cable 2 std wheel magnets (.7" D x .2" thick) Windows Basic DataMite software & manual	$ 599
BB2-BCT		15 ft Dual thermocouple breakout cable	25
BB2-BCA1		15 ft single analog breakout cable	20
BB2-BCA3		1 ft triple analog breakout cable	40
BB2-RPML		Dyno RPM Sensor and cable	50
BB2-IPUH		Inductive Pickup Cable	30
BB2-IPUP		Inductive Pickup for Primary Wire	45
BB2-IWS		Internal Weather Station Sensors	200
BB2-2KC		Black Box Dual K Thermocouple Converter	190

Note: The parts in the table below were for the original 4 channel DataMite. Most all of these parts can be ordered as replacements for the 4 channel systems, or as sensors for the Black Box II or DataMite II.

Part #	Picture	Description	Sug Retail
DTM128 (Obsolete, for replacement parts only)		Std DataMite Package, including: 128K flash memory (4.5 min @ 60 Hz, 9 min @ 30 Hz, 18 min @ 15 Hz). Data saved without power. Control panel (2 lighted push buttons) (not standard with Dyno systems as of July 2003) Serial downloading cable Vehicle wiring harness w 2 wheel sensors (15 ft leads to wheel sensors, 8 ft to ignition and 12 VDC). Dyno harness has only 1 wheel sensor but additional plug for inputting another channel. 4 std wheel magnets (.7" D x .2" thick) Windows basic DataMite software & manual	$ 559
DTM512 (Obsolete)		Same as DTM128 but with 512K Flash memory (4 times the recording time as the 128K system)	599
DTMxxxM (Obsolete)		Magneto compatible DTM system, with additional "noise rejecting’ metal box and spark signal condition box.	100
DTM-HRX		Custom harness with leads to lengths specified by customer. Allow 3 more weeks for delivery.	25
DTM-205		8 ft lead with 0-20 volt to 0-5 volt converter	35
DTM-AXX		Analog Converters convert most any type of signal into one that can be read by the DataMite ( for table)	110-235
DTM-AK		K Thermocouple for air temp with 8 ft lead	30
DTM-BM		4 Std magnets (.7" dia x .2" thick, better for high temperatures)	4
DTM-BP		Rechargable battery pack with recharger (approx 6 hours of recording time).	45
DTM-C2K		K Thermocouple for 12mm spark plug w 2 ft lead	45
DTM-C4K		K Thermocouple for 14mm spark plug w 2 ft lead	40
DTM-C50		50 ft Serial Extension Cable for Downloading	25
DTM-C25		25 ft Serial Extension Cable for Downloading	20
DTM-CP		Replacement control panel	65
DTM-EBS		Oxygen sensor threaded boss fitting to weld to exhaust pipe	3.50
DTM-EBSP		Allen head plug for Oxygen Sensor weldable boss	2.50
DTM-EGO		Exhaust gas oxygen (EGO) sensor (narrow band)	70
DTM-EKL		K Thermocouple 8 ft extension lead (cable)	25
DTM-EKLC		K Thermocouple custom length extension	35
DTM-EKM		Thermocouple 1/8" mounting hardware (steel exhaust compression fitting and HD boss)	6
DTM-EKB		1/8" Thermocouple weldable boss	2.70
DTM-EKBHD		1/8" Thermocouple heavy duty weldable boss	3.50
DTM-EKF		Thermocouple 1/8" exhaust compression fitting	2.90
DTM-EKFF		Thermocouple 1/8" fluid compression fitting (O rings)	2.90
DTM-EHCM		Hose Clamp Style Exhaust Thermocouple Mounting Kit	15
DTM-EKx		K Thermocouple (x=E for fast, exposed tip rec. for	45
DTM-FLT		Replacement 150-230 deg fluid temp sensor (special cable required for original installation)	30
DTM-HEGO		4 Wire Heated Exhaust gas oxygen (HEGO) sensor. Same as DTM-EGO but extra 2 wires for 12 VDC, 1 amp for user to wire to heat sensor. More stable.	100
DTM-HR		Extra standard harness w 2 wheel snsrs+4 magnets	70
DTM-ILCA		External Load Cell Amplifier	175
DTM-IPU		Inductive pickup for spark plug wire (note that a lesser cost option allows for this to be built in the DataMite box)	45
DTM-IPUC		Inductive Pickup Clamp provides an convenient way to attach inductive pickup to spark plug wire and signal enhancement. Standard method is wrap or tie IPU wire to spark plug wire. Still requires the DTM-IPU to work.	55
DTM-IPUCW		Inductive Pickup Clip for "purple wire" provides simple way to clip wire to plug wire. Easily removed if you need to place wire by coil-on-plug or wrap purple wire.	5
DTM-L1		1.5" Spring loaded linear displacement sensor	65
DTM-LD		Std 10 ft Lead wire with proper connector to DataMite harness or converter box. Sensor to be wired by user, schematic included.	15
DTM-LDC		Std 10 ft Lead with mating connector and connector on sensor as required.	40
DTM-LDCX		Custom length Lead with mating connector and connector on sensor as required.	50
DTM-LDX		Custom length Lead wired directly to sensor (no connector at sensor) with proper connector to DataMite harness or converter box.	35
DTM-Lxx		Linear displacement sensor (Ranges include 4, 5, 6 , 8 and 10 inches movement. Specify ranges with xx, for example DTM-L04 is a 4 inch sensor.) NOTE: Sensor costs increase with length of sensor. 8" is $255 and 10" is $390	245 (6")
DTM-MB		4 "Magnet head" plastic bolts (1/4 20 x 1" bolts)	40
DTM-OI		Optical Isolator protects computer (up to 2500 volts) from voltage spikes from engine passing through DataMite	100
DTMPxxx		Higher accuracy stainless steel pressure sensor (ranges include 25, 50, 75,100, 250, 500, 1000, 2500, 5000, 7500 and 10000 PSI). Specify range with xxx in 10s of PSI, for example, DTMP005 is 50 PSI. For 10000 PSI use 10K for xxx).	170
DTM-PH		Power harness (wire leads & connector of DTM-PS but you supply 12 V DC supply or 300 mAmp, like a battery.)	10
DTM-PS		110V AC wall outlet power supply, for downloading data to desk top PC. Recommended for Dyno systems.	25
DTM-RPMA		High temp aluminum RPM sensor.	35
DTM-SKT		Stuska (tm) Dyno Quick Connects for torque pressure sensor	60
DTM-SM		4 Small, rare earth magnets (.2" dia x .05" thick)	5
DTM-SPX		2" to 10" Cable Potentiometer	200
DTM-SRPM		Stuska (tm) Dyno RPM Adapter with active sensor added to harness. This mounts between dyno and mechanical tachometer cable.	225
DTM-SW		Position (on/off) switch with 10 ft lead	35

Dual Channel DataMite Analog Converters (convert to frequency output to be used on RPM input channels)

Part #	Picture	Description	Sug Retail
DTM-A1A		Single Channel DataMite Analog Converter 1 Accelerometer	190
DTM-A15		Single Channel DataMite Analog Converter 1 0-5 volt input	140
DTM-AA5		Dual Channel DataMite Analog Converter 1 Accelerometer, 1 0-5 volt input	215
DTM-AAA		Dual Channel DataMite Analog Converter 2 Accelerometers	240
DTM-AAK		Dual Channel DataMite Analog Converter 1 Accelerometer, 1 K Thermocouple	265
DTM-A1K		Single Channel DataMite Analog Converter 1 K Thermocouple	170
DTM-AKK		Dual Channel DataMite Analog Converter 2 K Thermocouples (replaced by BB2-2KC above)	225
DTM-A55		Dual Channel DataMite Analog Converter 2 0-5 volt Inputs	165
DTM-A5K		Dual Channel DataMite Analog Converter 1 0-5 volt input, 1 K Thermocouple	200

Prices of DataMite II components.

Note: Most prices quoted below are with the standard Molex connectors.
to see a comparison.

Part #	Picture	Description	Price
DT2-2M		Base DataMite II system with 5 RPM channels, 4 On/Off channels, 2 timer channels, 2 axis accelerometer (lateral and longitudinal), 2 Meg Memory, 2 'Wheel' RPM sensors with harness, push button control panel, downloading cable, Windows DataMite Analyzer software.	$1199
DT2-4AI		Activate four (4) analog inputs with wiring and connectors (sensors extra)	150
DT2-4M		2 Additional Meg Memory, 4 Meg Total	190
DT2-4KI		Activate four (4) K thermocouple inputs (exh temps) with wiring and connectors (sensors extra)	150
DT2-ACL1		Single axis remote mount accelerometer, +/- 2 Gs	160
DT2-AF1		Single Channel Wide Band UEGO A/F sensor and controller	399
DT2-AF1P		Single Channel Wide Band UEGO A/F sensor and controller with A/C Power Supply	449
DT2-AF2		Dual Channel Wide Band UEGO A/F sensor and controller	529
DT2-AF2P		Dual Channel Wide Band UEGO A/F sensor and controller with A/C Power Supply	579
DT2-AFCC		A/F Sensor (UEGO) Calibration Checker.	499
DT2-AFG		Single Wide Band UEGO A/F sensor and controller gauge.	299
DT2-AFR		Remote sampling system for DT2-AF1P, requires 110 VAC power. 220 VAC option available.	459
DT2-AFR2		Dual remote sampling system for DT2-AF2P, requires 110 VAC power. 220 VAC option available.	599
DT2-AFRC		'Exhaust Pipe' clamp which attach to probe(s) of DT2-AFR remote sampling system to easily, quickly clamp probe to exhaust pipe.	45
DT2-AFS		Replacement Bosch Sensor for DT2-AFx UEGO systems	80
DT2-AFSB		Exact replacement weldable boss fitting (with shoulder) for DT2-AFS A/F Oxygen sensor	6
DT2-AFSBC		Exact replacement cap for weldable boss fitting DT2-AFSB above	9
DT2-K3		3" K thermocouple sensor (exh temps) with stainless steel braided shielding	45
DT2-3GS		Third (3rd) axis accelerometer	150
DT2-5KC		5 ft Thermocouple Breakout Cable for 4 Thermocouples	70
DT210KC		10 ft Thermocouple Breakout Cable for 4 Thermocouples	80
DT215KC		15 ft Thermocouple Breakout Cable for 4 Thermocouples	90
DT2-4K		Additional 2 Meg Ram (4 Meg total memory, doubles the recording time)	190
DT2-ABC		1 ft Analog Sensor Breakout Cable for 4 sensors with Molex Leads (pigtails)	40
DT2-RBC		1 ft RPM Breakout Cable with 4 pin Inductive Pickup Molex Connector and 6 pin Wheel RPM Molex Connectors (included with system)	65
DT2-SBC		1 ft Switch and Timer Breakout Cable with 2 pin Connectors	60
DT2-IRA		Infra Red (non contract), std response, analog 0-5 volt tire temperature sensor.	175
DT2-IRAF		Infra Red (non contract), fast responding, analog 0-5 volt tire temperature sensor.	195
DT2-SLD		10 ft Switch extension lead with Molex Connector (plugs into DT2-SBC)	12
DT2-LB		In car lap timer and beacon. Requires DT2-SBC.	400
DTM-LD		10 ft Analog sensor extension lead with Molex Connector (plugs into DT2-ABC). Sensor to be wired by user, schematic included.	12
DT2-LDC		"S" Beam Load Cell for measuring force, typically for dynamometer torque. Many ranges available, from 25 to 5000 lbs force, some at an increased price.	425
DT2-LDCA		Load Cell Amp, required for DT2-LDC. This can be wired for load cell to work in either compression or tension.	175
DT2-RLD		Standard RPM sensor and 15 ft extension lead with Molex Connector (plugs into DT2-RBC)	40
DT2-ARL		Active RPM sensor with internal magnet (triggers on large, ferrous metal targets) and 15 ft extension lead with Molex Connector (plugs into DT2-RBC). Generally more stable in high vibration installation.	70
DT2-MRL		Active RPM sensor (which triggers on South pole only of magnet targets) and 15 ft extension lead with Molex Connector (plugs into DT2-RBC). Generally more stable in high vibration installation.	70
DT2-RPMR		Reflective Optical RPM Sensor. Triggers on reflective tape target about 1/2 inch in diameter, from distances up to 30" away. Has alignment beam and signal indicator LED.	199
DT2-CP		Pushbutton Control Panel for DataMite II	65
DT2-PS		110 VAC 1 Amp Power Supply for DataMite II	50
DT2-PC		Power connector and cable for DataMite II (included with system)	15
DT2-USB		USB to Serial Port Adapter. Adapts a computer's USB port to Serial (COM) so the computer can read the DataMite's serial data.	35
DT2-RPxxx		Resistive type, less expensive Pressure Sensor. xxx stands for, 30, 80, 150 and 400 psi ranges.	85
DT2-SHM		Universal shock travel sensor mounting kit	28
DT2-TC4		4 channel K thermocouple amplifier and recorder w power input connector and serial output connector. Other leads are covered with shrink tubing to prevent shorting. for price of typical K thermocouples, DT2-K3.	399
DT2-TC4M		Add 4 Molex connectors to DT2-TC4 for 4 0-5 volt outputs.	40
DT2-TC4A		Add 1 9 pin Amp connector to DT2-TC4 for plugging directly into DataMite II. This eliminates the need for typical DT2-ABC analog breakout cable.	40

Many of the standard DataMite sensors are compatible with the DataMite II, Black Box II, and DataMite USB III or Mini. The price may be slightly different when used on different loggers. Lead lengths are typically 15-18 ft long. If you need special length leads, we can customize the lengths for a nominal charge.

Data loggers have a limited 1 year warranty.

Package Prices

DataMite Mini USB Basic Inertia Dyno Package (typically for small engines) ( for picture)

Qty Part # Description Each Price

1 DMM-IDP DataMite Mini USB Inertia Dyno Package 499 499

Total before shipping $499

DataMite Mini USB Professional Inertia Dyno Package (typically for small engines) ( for picture)

Qty Part # Description Each Price

1   DMM-IDP DataMite Mini USB Inertia Dyno Package    499   499
1   DTM-IPU Inductive Pickup Signal Conditioning       45    45
1   DMMIPUHU Inductive Pickup Harness Upgrade           20    20
1 DTM-Pro Pro version of Dyno Software              100   100
1   DMM-BCT 15 ft Dual thermocouple breakout cable     25    25
1   BB2-2KC Black Box Dual K Thermocouple Converter   190   190
1   DTM-EKE Exhaust K Thermocouple                     45    45
1   DTM-EKC Hose Clamp EGT Mounting Kit                15    15
1   DTM-CHT 14 mm cylinder head thermocouple           45    45
1   DMM-IWS Internal weather sensors and fan          175   175

Total before shipping $1159

Note: This Mini DataMite system is "maxed out". No future expansion of additional channels (sensors) is possible.

DataMite III USB Professional Inertia Dyno Package (typically for small engines) ( for picture)

Qty Part # Description Each Price

1   DT3-IDP DataMite III USB Inertia Dyno Package    699   699
1   DTM-IPU Inductive Pickup Signal Conditioning       45    45
1   DT3-TC4 4 Internal Thermocouples                  200   200
1   DT3-IWS Internal weather sensors and fan          175   175
1   DTM-AK   Air Temp Thermocouple (for weather)        35    35
1 DTM-Pro Pro version of Dyno Software              100   100
1   DTM-EKE 16 ft Exhaust K Thermocouple               48    48
1   DTM-CHT 14 mm cylinder head thermocouple          45    45
1   DTM-EKL 15 ft head thermocouple extension lead     25    25

             Total before shipping                        $ 1372

Note: This system has 10 additional analog input channels (which could be pressures, force (torque), or more temperatures via thermocouple converters), 1 unused thermocouple channels, and 1 unused RPM channel for future expansion.

DataMite III USB Professional Water Brake Dyno Package (for typical V-8 engines) ( for picture)

Qty Part # Description Each Price

1   DT3-IDP DataMite III USB Inertia Dyno Package    699   699
1   DT3-TC4 4 Internal Thermocouples                  200   200
3   DMM-BCT 15 ft Dual thermocouple breakout cable     25    75
3   BB2-2KC Black Box Dual K Thermocouple Converter   190   570
1   DT3-IWS Internal weather sensors and fan          175   175
1 DTM-Pro Pro version of Dyno Software              100   100
8   DTM-EKE Exhaust K Thermocouple                     45   360
2   DTM-EKS Sheathed fluid temp thermocouple           45    90
1   DT3TCE10 10 ft 4 channel theromcpl extension cable 75    75
1   DTMP015 150 PSI torque pressure sensor            170   170
1   DTMP010 100 PSI oil pressure sensor                170   170
1   DT3BCA5 5 channel analog breakout cable            55    55
1   DT3BCA3 3 channel analog breakout cable            45    45

Total before shipping $ 2784

Note: This system measures torque via a pressure sensor, RPM via a magnetic sensor, 8 exhaust temperatures, one water temperature, one oil temperature, one oil pressure, and automatic weather corrections. A pressure sensor can only be used to measure torque if you are currently using a hydraulic load cell (cylinder) and pressure gauge to measure torque. You can substitute a load cell and amplifier instead of the pressure sensor for about $450 more than the quote above.

DataMite III USB Sportsman Drag Racing Package ( for picture)

Qty Part # Description                               Each Price

1   DT3-DRS DataMite III USB Drag Racing System        699   699
1   DT3-TC4 4 Internal K Thermocouple channels         200   200
2   DTM-EKE Exhaust K Thermocouple                      45    90
2   DTM-EKS Sheathed K Thermocouple for fluid temps     45    90
1   DT3-IWS Internal weather sensors and fan           175   175
1   Disc    Package Discount                          -255 -255

            Total before shipping                           $999

DataMite III USB Road Racing/Circle Track Starter Package ( for picture)

Qty PN      Description                                            Each Price

1   DT3-RRS DataMite III USB Road Race/Circle Track System          699   699
1   DT3-GPS External fast responding GPS (global positioning)       349   349
            sensor for lap timing and track mapping
1   Disc    Package Discount                                       -100 -100

            Total before shipping                                        $949

DataMite III USB Road Racing/Circle Track “Suspension Tuner” Package ( for picture)

Qty Part # Description                                             Each Price

1   DT3-RRS DataMite III USB Road Race/Circle Track System           699   699
1   DT3-PRR Pro version of Road Race/Circle Track Software           100   100
1   DT3-GPS External fast responding GPS (global positioning)        349   349
            sensor for lap timing and track mapping
5   DTM-L08 Linear sensor for shock absorber and steering motion     255 1275
5   DT2-SHM Universal shock travel sensor mounting kit                28   140
1   DTM-SP2 2.8" Cable Potentiometer for throttle movement           200   200
1   DTMP1M 1000 PSI brake pressure sensor                           170   170
2   DT3BCA5 5 channel analog breakout cable                           55   110
1   SAF20DL Suspension Analyzer Full Vehicle w Data Logger features 599   599
1   Disc    Package Discount                                        -200 -200

            Total before shipping                                        $3442

NOTES:

Systems can be completely customized with any combination of options. Pressure sensors are high quality stainless steel and all the same price with ranges from 25 to 10,000 PSI. Less expensive pressure sensors are available.

Typical lead lengths are 15-18 ft. If you need longer or shorter lead lengths, please let us know and we'll customize your lengths at a nominal charge.
